Cell Collection Kit

Problem:

A way to safely collect and ship human cells for testing.


Solution:

A plastic ejectable brush was developed to easily collect and safely ship the sample to an outside lab.

Helios Inc. | Palo Alto, CA | 2016

A technical illustration of a disposable cell-collection device.
A technical illustration of the plastic head of a disposable cell-collection device.
A technical illustration of the plastic head of a disposable cell-collection device.
A technical illustration of a cell collection device being placed inside of a tube with liquid for mailing.
A technical illustration of a cell collection device being released into a plastic tube with liquid for mailing.
Wireframe rendering of a transparent cylindrical tube with the cell collection head inside. Ready to be mailed back to a clinic for testing.
A disposable cell collection device with a purple main body and a head that can be released into a tube for mailing by squeezing the purple handle.
A disposable cell collection device with a purple main body and a head that can be released into a tube for mailing by squeezing the purple handle.
A disposable cell collection device with a purple main body and a head that can be released into a tube for mailing by squeezing the purple handle.
A disposable cell collection device with a purple main body and a head that can be released into a tube for mailing by squeezing the purple handle.
